Iscar - Arbor Hole Connection, 1/16" Cutting Width, 0.3937" Depth of Cut, 50mm Cutter Diam, 0.315" Hole Diam, 5 Tooth Indexable Slotting Cutter - TGSF Toolholder, TAG N-A, TAG N-C/W/M, TAG N-J/JS/JT, TAG N-LF, TAG N-MF, TAG N-UT Insert
Item #: 30705453
Brand: Iscar
Model #: 2302610
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 1.60 |
| Cutting Width (Decimal Inch) | 0.0630 |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Cutter Diameter (mm) | 50.00 |
| Cutter Diameter (Decimal Inch) | 1.9685 |
| Hole Diameter (mm) | 8.00 |
| Hole Diameter (Decimal Inch) | 0.3150 |
| Number of Teeth | 5 |
| Toolholder Style | TGSF |
| Series | TangSlit(TGSF) |
| Insert Style | TAG N-A; TAG N-C/W/M; TAG N-J/JS/JT; TAG N-LF; TAG N-MF; TAG N-UT |
| Staggered Tooth | No |
| Number of Cutter Inserts | 5 |
| Insert Holding Method | Clamp |
| Maximum RPM | 1600 |
| Hub Diameter (mm) | 28.00 |
| Hub Diameter (Decimal Inch) | 1.1024 |
| Radius | No |
| Complete Insert Compatibility1 | TAG N1.4C; TAG N1.4J; TAG N1.6C; TAG N1.6J; TAG N2.4C; TAG N2A; TAG N2C; TAG N2J; TAG N2JS; TAG N2JT; TAG N2LF; TAG N2UT; TAG N3A; TAG N3CB; TAG N3LF; TAG N3UT; TAG N4A; TAG N4UT; TAG N5UT; TAG N6UT |
