Iscar - Shell Mount Connection, 0.4134" Cutting Width, 1.0236" Depth of Cut, 100mm Cutter Diam, 1-1/16" Hole Diam, 6 Tooth Indexable Slotting Cutter - FDN-CALN12 Toolholder, LNET 12-TN, LNET 12-TN-MM, LNET 12..-30X1-N Insert
Item #: 30707442
Brand: Iscar
Model #: 3103988
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount |
| Cutting Width (mm) | 10.50 |
| Cutting Width (Decimal Inch) | 0.4134 |
| Maximum Depth of Cut (mm) | 26.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.0236 |
| Cutter Diameter (mm) | 100.00 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Hole Diameter (mm) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.0630 |
| Number of Teeth | 6 |
| Toolholder Style | FDN-CALN12 |
| Series | TangMill(FDN-CALN15) |
| Insert Style | LNET 12-TN; LNET 12-TN-MM; LNET 12..-30X1-N |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Maximum Cutting Width (Decimal Inch) | 0.5748 |
| Maximum Cutting Width (mm) | 14.60 |
| Hub Diameter (mm) | 55.00 |
| Hub Diameter (Decimal Inch) | 2.1654 |
| Radius | No |
| Complete Insert Compatibility2 | LNET 124808-TN-MM; LNET 1250-30X1-N; LNET 125008-TN-MM |
| Complete Insert Compatibility1 | LNET 1235-30X1-N; LNET 123504-TN; LNET 123508-TN; LNET 123508-TN-MM; LNET 1240-30X1-N; LNET 124004-TN; LNET 124008-TN; LNET 124008-TN-MM; LNET 1245-30X1-N; LNET 124504-TN; LNET 124508-TN-MM; LNET 1248-30X1-N |
