Iscar - Shell Mount B Connection, 0.5512" Cutting Width, 1-1/16" Depth of Cut, 100mm Cutter Diam, 1-1/16" Hole Diam, 6 Tooth Indexable Slotting Cutter - FDN-CALN11 Toolholder, LNHT 1106 PN-N HT, LNHT 1106 PN-R HT Insert
Item #: 30707459
Brand: Iscar
Model #: 3103994
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount B |
| Cutting Width (mm) | 14.00 |
| Cutting Width (Decimal Inch) | 0.5512 |
| Maximum Depth of Cut (mm) | 27.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.0630 |
| Cutter Diameter (mm) | 100.00 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Hole Diameter (mm) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.0630 |
| Number of Teeth | 6 |
| Toolholder Style | FDN-CALN11 |
| Series | TangMill(FDN-CALN15) |
| Insert Style | LNHT 1106 PN-N HT; LNHT 1106 PN-R HT |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Maximum Cutting Width (Decimal Inch) | 0.7677 |
| Maximum Cutting Width (mm) | 19.50 |
| Hub Diameter (mm) | 55.00 |
| Hub Diameter (Decimal Inch) | 2.1654 |
| Keyway Width (Decimal Inch) | 0.4882 |
| Keyway Width (mm) | 12.40 |
| Radius | No |
| Complete Insert Compatibility1 | LNHT 1106PN-N HT; LNHT 1106PN-R HT |
