Iscar - 12 Inserts, 2-1/2" Cut Diam, 1" Arbor Diam, 0.303" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 1-3/4" High, HP AN.. 07.. Insert Compatibility, Series Heliplus
Item #: 30707475
Brand: Iscar
Model #: 3104164
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 2.5000 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 0 |
| Overall Height (Decimal Inch) | 1.7500 |
| Insert Compatibility | HP AN.. 07.. |
| Series | Heliplus |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.3030 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 12 |
| Insert Holding Method | Screw |
| Cutter Style | HP F90AN-07 |
| Keyway Width (Decimal Inch) | 0.3750 |
| Pitch | Fine |
| Counterbore Diameter (Decimal Inch) | 1.3800 |
| Complete Insert Compatibility | HP ANCR 070204PNFR; HP ANCR 070204PNFR-P; HP ANCT 070202 PN-R; HP ANCT 070204PN-R; HP ANKT 0702 PN-R; HP ANKT 070202PNTR; HP ANKT 0702PNTR; HP ANKW 070204PNTR |
