Iscar - 3.388" Cut Diam, 1" Arbor Hole, 1.18" Max Depth of Cut, 60° Indexable Chamfer & Angle Face Mill - 9 Inserts, T490 LN.. Insert, Right Hand Cut, Through Coolant, Series Helitang
Item #: 30708879
Brand: Iscar
Model #: 3106949
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 3.3880 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 60 |
| Overall Height (Decimal Inch) | 2.1650 |
| Insert Compatibility | T490 LN.. |
| Series | Helitang |
| Through Coolant | Yes |
| Maximum Depth of Cut (Decimal Inch) | 1.1800 |
| Number of Cutter Inserts | 9 |
| Insert Holding Method | Screw |
| Cutter Style | T460 SM |
| Hub Diameter (Decimal Inch) | 2.3600 |
| Keyway Width (Decimal Inch) | 0.3750 |
| Cutting Direction | Right Hand |
| Maximum Insert Radius (Decimal Inch) | 0.1220 |
| Counterbore Diameter (Decimal Inch) | 0.7800 |
| Complete Insert Compatibility | T490 LNAR 1306PN-R; T490 LNAR 1306PN-R-P; T490 LNHT 1306PN-R PL; T490 LNHT 1306PNTL; T490 LNHT 1306PNTR; T490 LNMT 1306PNTR; T490 LNMT 1306PNTR-CS |
