Brand: Widia / Part #: 2008116
Item #: 32893869
Brand: Widia
Model #: 2008116
Product Specifications
| End Type | Double-Ended |
| Cutting Direction | Neutral |
| Hand | Neutral |
| Blade Height (mm) | 32.00 |
| Blade Height (Decimal Inch) | 1.2598 |
| Blade Width (Decimal Inch) | 0.0945 |
| Blade Width (mm) | 2.40 |
| Blade Overall Length (Decimal Inch) | 5.9055 |
| Blade Overall Length (mm) | 150.00 |
| Blade Style | ProGroove |
| Compatible Insert Style | PGM; PGR; PGS; PGU |
| Compatible Insert Size Code | 3 |
| Tool Material | Steel |
| Insert Holding Method | Clamp |
| Maximum Workpiece Diameter (mm) | 100.00 |
| Maximum Workpiece Diameter (Decimal Inch) | 3.9370 |
| Series | WGC |
| Insert Style | PGM; PGR; PGS; PGU |
| Cutting Tool Application | Cut-Off |
| Primary Workpiece Material | Universal |
| Insert Seat Size | 3 |
| Maximum Depth of Cut (Decimal Inch) | 1.9685 |
| Maximum Depth of Cut (mm) | 50.00 |
| Minimum Workpiece Diameter (Decimal Inch) | 0.0000 |
| Cutting Height (mm) | 25.00 |
| Cutting Height (Decimal Inch) | 0.9842 |
| Minimum Insert Width (Decimal Inch) | 0.1181 |
| Minimum Insert Width (mm) | 3.00 |
| Maximum Insert Width (mm) | 3.99 |
| Maximum Insert Width (Decimal Inch) | 0.1571 |
| Manufacturers Catalog Number | 12251353000 |
