PRO-SOURCE - 3/8", 2/2 Way Stacking Solenoid Valve - 110 VAC, 4.12 CV Rate, 3.98" High x 2.76" Long
Item #: 31880149
Brand: PRO-SOURCE
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | 2/2 Way |
| Actuator Type | Assisted Lift |
| Number of Positions | 2 |
| Number of Positions | 2 Position |
| Valve Type | 2-Way |
| Return Type | Spring |
| Voltage | 110 VAC |
| CV Rating | 4.120 |
| Inlet Size (Inch) | 3/8 |
| Outlet Size (Inch) | 3/8 |
| Cubic Feet per Minute | 87.90 |
| Length (Decimal Inch) | 2.760 |
| Height (Inch) | 3.98 |
| Maximum Temperature (F) | 194 |
| Maximum Working Pressure (psi) | 100 |
| For Use With | Compressed Air; Light Oil; Water |
