PRO-SOURCE - 1/8", 5/2 Way Body Ported Stacking Solenoid Valve - 24 VDC, 0.6 CV Rate, 1.36" High x 3.88" Long
Item #: 31880339
Brand: PRO-SOURCE
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | 5/2 Way Body Ported |
| Actuator Type | Internal Pilot |
| Number of Positions | 2 |
| Number of Positions | 2 Position |
| Valve Type | 5-Way |
| Return Type | Spring |
| Voltage | 24 VDC |
| CV Rating | 0.600 |
| Inlet Size (Inch) | 1/8 |
| Outlet Size (Inch) | 1/8 |
| Cubic Feet per Minute | 31.89 |
| Length (Decimal Inch) | 3.880 |
| Height (Inch) | 1.36 |
| Maximum Temperature (F) | 122 |
| Maximum Working Pressure (psi) | 113 |
| For Use With | Compressed Air |
