PRO-SOURCE - 1/2", 2/2 Way Steam Series Stacking Solenoid Valve - 110 VAC, 4.5 CV Rate, 4.19" High x 2.76" Long
Item #: 31880420
Brand: PRO-SOURCE
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | 2/2 Way Steam Series |
| Actuator Type | Pilot |
| Number of Positions | 2 |
| Number of Positions | 2 Position |
| Valve Type | 2-Way |
| Return Type | Air Pilot |
| Voltage | 110 VAC |
| CV Rating | 4.500 |
| Inlet Size (Inch) | 1/2 |
| Outlet Size (Inch) | 1/2 |
| Cubic Feet per Minute | 105.95 |
| Length (Decimal Inch) | 2.760 |
| Height (Inch) | 4.19 |
| Maximum Temperature (F) | 356 |
| Maximum Working Pressure (psi) | 145 |
| For Use With | Compressed Air; Hot Water; Steam |
