Iscar - 10mm to 10.4mm Diam, 5xD, 50mm Max Depth, 10mm Shank Diam, 106.2mm OAL, Replaceable-Tip Drill - FCP, ICK, ICK-2M, ICM, ICN, ICP, iCP-2M Insert, 10 Seat Size, 32075186 Toolholder, Series UniSumoCham
Item #: 32075186
Brand: Iscar
Model #: 3260163
Exact Tooling IR#: 04
Features and Benefits
Weldon flats are designed with a set screw that secures the tool for increased torque and reduced slipping. The diameters are typically different from the diameter of the cutting part of the tool.
| Product Specifications | |
|---|---|
| Series | UniSumoCham |
| Minimum Drill Diameter (mm) | 10.00 |
| Minimum Drill Diameter (Decimal Inch) | 0.3937 |
| Maximum Drill Diameter (mm) | 10.40 |
| Maximum Drill Diameter (Decimal Inch) | 0.4094 |
| Drill Depth by Diameter Ratio | 5xD |
| Maximum Drill Depth (Decimal Inch) | 1.9685 |
| Maximum Drill Depth (mm) | 50.00 |
| Shank Diameter (mm) | 10.00 |
| Shank Diameter (Decimal Inch) | 0.3937 |
| Insert Style | FCP; ICK; ICK-2M; ICM; ICN; ICP; iCP-2M |
| Insert Seat Size | 10 |
| Toolholder Style | DCNS |
| Through Coolant | Through Coolant |
| Shank Type | Weldon Flat |
| Body Length (mm) | 65.20 |
| Body Length (Decimal Inch) | 2.5670 |
| Overall Length (mm) | 106.20 |
| Overall Length (Decimal Inch) | 4.1811 |
| Shank Length (mm) | 41.00 |
| Shank Length (Decimal Inch) | 1.6142 |
