Heli-Coil - 1,000 Inserts, #6-32 UNC, 1D, Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.138 Inch Overall Length, 0.178 to 0.193 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32884280
Brand: Heli-Coil
Model #: 3585-06CNW138S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #6-32 |
| Overall Insert Length (Decimal Inch) | 0.1380 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1000 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1780 |
| Maximum Outside Diameter (Decimal Inch) | 0.1930 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 2-3/4 |
| Maximum Locking Torque (In/Lb) | 6 |
| Minimum Break Away Torque (In/Lb) | 1.00 |
| Thread Standard | UNC |
| Material Grade | 304 |
