Boston Gear - 8 Pitch, 3" Pitch Diam, 24 Tooth Spur Gear - 1-1/4" Face Width, 7/8" Bore Diam, 2.06" Hub Diam, 14.5° Pressure Angle, Steel
Item #: 36682375
Brand: Boston Gear
Model #: NH24A
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Spur Gear |
| Number of Teeth | 24 |
| Hub Diameter (Decimal Inch) | 2.0600 |
| Pitch Diameter (Decimal Inch) | 3.0000 |
| Bore Diameter (Decimal Inch) | 0.8750 |
| Material | Steel |
| Face Width (Decimal Inch) | 1.2500 |
| Pressure Angle | 14.5 |
| PSC Code | 3020 |
