Turning Insert: CCGT251505MEFM T1500Z, Cermet
Item #: 23214455
Brand: Sumitomo
Model #: 104AAMA
Product Specifications
| ANSI Insert Code | CCGT2.51.50.5 |
| ISO Insert Code | CCGT |
| Relief Angle | 7 |
| Insert Style | CCGT |
| Corner Radius (mm) | 0.20 |
| Included Angle | 80 |
| Manufacturer Grade | T1500Z |
| Coating/Finish | AlN |
| Insert Hand | Neutral |
| Insert Thickness | 2.38 |
| Series | T1500Z |
| Inscribed Circle (Decimal Inch) | 0.3125 |
| Inscribed Circle (mm) | 7.94 |
| Insert Material | Cermet |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Grade Characteristics | Steel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness |
| Side Clearance | Positive |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 2.8000 |
| Insert Holding Method | Screw |
| Rake | Positive |
| Insert Length (mm) | 8.00 |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material Code | P; K; M |
| Chip Breaker | MESC |
| ANSI Size Code | 2.51.50.5 |
| UNSPSC Code | 23242105 |
| Insert Size Code | 2.51.50.5 |
