Kennametal - 3" Cut Diam, 1" Arbor Hole, 5.5mm Max Depth of Cut, 46.5° Indexable Chamfer & Angle Face Mill - 8 Inserts, ON.X080608.. Insert, Right Hand Cut, 8 Flutes, Series MILL 16
Item #: 37737541
Brand: Kennametal
Model #: 6134103
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 3 |
| Cutting Diameter (mm) | 76.20 |
| Cutting Diameter (Decimal Inch) | 3.0000 |
| Arbor Hole Diameter (mm) | 25.40 |
| Arbor Hole Diameter (Inch) | 1 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 46.5 |
| Overall Height (Inch) | 1-3/4 |
| Overall Height (Decimal Inch) | 1.7500 |
| Insert Compatibility | ON.X080608.. |
| Series | MILL 16 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 5.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.2150 |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw/Clamp |
| Number of Flutes | 8 |
| Hub Diameter (mm) | 55.60 |
| Maximum RPM | 8200 |
| Cutting Direction | Right Hand |
| Toolholder Material | Steel |
| Overall Length (Inch) | 1 |
| Overall Length (Decimal Inch) | 1.7500 |
| Number of Flutes | 8 |
| Minimum Cutting Diameter (Decimal Inch) | 3.0000 |
| Maximum RPM | 8200 |
| Toolholder Material | Steel |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.0000 |
