Kennametal - 11 Inserts, 127mm Cutter Diam, 2.5mm Max Depth of Cut, Indexable High-Feed Face Mill - 1-1/2" Arbor Hole Diam, 63mm High, 7792VXD12 Toolholder, XD..1205.. Inserts, Series 7792VX
Item #: 38067948
Brand: Kennametal
Model #: 5658171
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 127.00 |
| Maximum Depth of Cut (mm) | 2.50 |
| Arbor Hole Diameter (Decimal Inch) | 1.5000 |
| Overall Height (mm) | 63.00 |
| Series | 7792VX |
| Cutter Style | 7792VXD12 |
| Number of Cutter Inserts | 11 |
| Insert Compatibility | XD..1205.. |
| Cutting Direction | Right Hand |
| Maximum RPM | 13000 |
| Number of Flutes | 11 |
| Through Coolant | Yes |
