Kennametal - 24 Inserts, 200mm Cut Diam, 60mm Arbor Diam, 1/4" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 63mm High, KSDR100031E1W4S Insert Compatibility, Series KBDM
Item #: 38161071
Brand: Kennametal
Model #: 6044687
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 200.00 |
| Arbor Hole Diameter (mm) | 60.00 |
| Lead Angle | 0 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | KSDR100031E1W4S |
| Series | KBDM |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.2500 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 24 |
| Insert Holding Method | Wedge |
| Hub Diameter (mm) | 130.50 |
| Maximum Body Diameter (Decimal Inch) | 7.8150 |
| Number of Adjustable Pockets | 24 |
| Maximum RPM | 12240 |
| Toolholder Material | Steel |
