Samchully - 1 Spindle, 432mm Horizontal & Vertical Rotary Table - 500 kg (1100 Lb) Max Horiz Load, 283mm Centerline Height, 194mm Through Hole
Item #: 39473434
Brand: Samchully
Model #: S430I5HP
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Indexer Type | Rotary Table |
| Number of Spindles | 1 |
| Collet Compatibility | None |
| Maximum RPM | 25 |
| Table Diameter (mm) | 432.00 |
| Setting Position | Horizontal; Vertical |
| Maximum Horizontal Load Capacity (Lb.) | 1100 |
| Maximum Horizontal Load Capacity (kg) | 500 |
| Maximum Vertical Load Capacity (Lb.) | 550 |
| Maximum Vertical Load Capacity (kg) | 250 |
| Centerline Height (mm) | 283.00 |
| Through Hole Size (mm) | 194.00 |
| Repeatability (sec.) | 4.00 |
| Number of T-Slots | 8 |
| Motor Type | AC Servo |
