Tapmatic - 5/8" Straight Shank Diam Tension & Compression Tapping Chuck - #0 to 1/4" Tap Capacity, 1-1/2" Projection
Item #: 41444332
Brand: Tapmatic
Model #: 023262
Exact Tooling IR#: 04
Features and Benefits
Tension and compression tapping styles are engineered to automatically compensate for machine feed, pitch and tap rates. They feature a spring design that allows the tap to float during the cutting cycle without affecting the pitch.
Straight shanks are used for general purpose machining and commonly have a larger diameter than taper shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Tension & Compression |
| Shank Type | Straight Shank |
| Shank Diameter (Inch) | 5/8 |
| Minimum Tap Capacity (Inch) | #0 |
| Maximum Tap Capacity (Inch) | 1/4 |
| Maximum Tap Capacity (mm) | M7 |
| Projection (Inch) | 1-1/2 |
| Quick Change | No |
| Collet System | Rubber |
| Tension (mm) | 4.50 |
| Compression (mm) | 6.00 |
| Overall Length (mm) | 53.00 |
| Through Coolant | No |
