Scientific Cutting Tools - 1-1/16 - 12" Port, 1.665" Spotface Diam, 3/4" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44039808
Brand: Scientific Cutting Tools
Model #: AND10050-12RL
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AND 10050 |
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 1.0620-12 |
| Port Thread Size (Inch) | 1-1/16 - 12 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 12.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.750 |
| Tube Outside Diameter Compatibility (Inch) | 3/4 |
| Minimum Pilot Diameter (Decimal Inch) | 0.9760 |
| Maximum Pilot Diameter (Decimal Inch) | 1.0885 |
| Spotface Diameter (Decimal Inch) | 1.6650 |
| Pilot Length (Decimal Inch) | 0.7930 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | Bright |
| Head Length (Decimal Inch) | 1.8200 |
| Overall Length (Decimal Inch) | 3.9400 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Shank Length (Decimal Inch) | 2.1200 |
| Seal Angle | 30 |
| Thread Type | UN |
| Flute Type | Straight |
| Number of Flutes | 4 |
