Walter-Titex - 9.5mm 140° Solid Carbide Jobber Drill - Multilayer TiAlN Finish, Right Hand Cut, Spiral Flute, Straight Shank, 139mm OAL - Exact Tooling

Walter-Titex - 9.5mm 140° Solid Carbide Jobber Drill - Multilayer TiAlN Finish, Right Hand Cut, Spiral Flute, Straight Shank, 139mm OAL


Item #: 41790718
Brand: Walter-Titex
Model #: 6901165
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Multilayer Titanium Aluminum Nitride (TiAlN) is a blended coating that is more efficient than TIN. It offers a high level of wear resistance at higher cutting speeds and used on high alloy steels and cast iron.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 9.50
Drill Bit Size (Decimal Inch) 0.3740
Drill Point Angle 140
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating Multilayer TiAlN
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through Yes
Flute Length (mm) 95.00
Flute Length (Decimal Inch) 3.7400
Overall Length (mm) 139.00
Overall Length (Decimal Inch) 5.4720
Flute Length x Diameter Ratio 5xD
Shank Diameter (mm) 10.00
Shank Diameter (Decimal Inch) 0.3940
Maximum Drilling Depth (Decimal Inch) 3.1500
Maximum Drilling Depth (mm) 80.00
Drill Point Length (mm) 1.73
Drill Point Length (Decimal Inch) 0.0680
Number of Flutes 2
Series/List Xtreme INOX
$ 279.28
