Kennametal - 100mm Cut Diam, 32mm Arbor Hole, 4.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 6 Inserts, HNGJ 0905.. Insert, Right Hand Cut, 6 Flutes, Through Coolant, Series KSHR
Item #: 41947276
Brand: Kennametal
Model #: 3749961
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 100.00 |
| Cutting Diameter (Decimal Inch) | 3.9370 |
| Arbor Hole Diameter (mm) | 32.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.2598 |
| Lead Angle | 45 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | HNGJ 0905.. |
| Series | KSHR |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1770 |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | KSHR |
| Number of Flutes | 6 |
| Hub Diameter (mm) | 80.00 |
| Maximum RPM | 6300 |
| Cutting Direction | Right Hand |
| Pitch | Extra Coarse |
