Kennametal - 63.9mm Cut Diam, 22mm Arbor Hole, 6.6mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 4 Inserts, SECX-EN GN\xB6SECX-GD2\xB6SECX-SN GN Insert, Right Hand Cut, 4 Flutes, Through Coolant, Series Beyond Blast KSSM
Item #: 42689323
Brand: Kennametal
Model #: 4137779
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 63.90 |
| Cutting Diameter (Decimal Inch) | 2.5157 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 1.5748 |
| Overall Height (mm) | 40.00 |
| Insert Compatibility | SECX-EN GN; SECX-GD2; SECX-SN GN |
| Series | Beyond Blast KSSM |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 6.60 |
| Maximum Depth of Cut (Decimal Inch) | 0.2598 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Number of Flutes | 4 |
| Maximum Body Diameter (Decimal Inch) | 1.9685 |
| Maximum RPM | 18400 |
| Cutting Direction | Right Hand |
