Accupro - CAT50 Dual Contact Taper Shank 5/8" Hole End Mill Holder/Adapter - 1-21/32" Nose Diam, 4" Projection, Through-Spindle & DIN Flange Coolant
Item #: 42832907
Brand: Accupro
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Dual Contact Taper |
| Taper Size | CAT50 |
| Hole Diameter (Inch) | 5/8 |
| Nose Diameter (Inch) | 1-21/32 |
| Projection (Inch) | 4 |
| Projection (Decimal Inch) | 4.0000 |
| Through Coolant | Yes |
| Clamping Depth (mm) | 40.89 |
| Clamping Depth (Decimal Inch) | 1.6100 |
| Overall Length (Decimal Inch) | 8.0000 |
| Overall Length (mm) | 203.20 |
| Balanced to (RPM) | 25000 |
| TIR (Decimal Inch) | 0.0002 |
| Coolant Type | Through-Spindle & DIN Flange |
| Retention Knob Thread Size | 1-8 |
