Accupro - CAT50 Dual Contact Taper Shank 3/4" Hole End Mill Holder/Adapter - 1-57/64" Nose Diam, 3" Projection, Through-Spindle & DIN Flange Coolant
Item #: 42832923
Brand: Accupro
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Dual Contact Taper |
| Taper Size | CAT50 |
| Hole Diameter (Inch) | 3/4 |
| Nose Diameter (mm) | 48.00 |
| Nose Diameter (Inch) | 1-57/64 |
| Projection (Inch) | 3 |
| Projection (Decimal Inch) | 3.0000 |
| Through Coolant | Yes |
| Clamping Depth (mm) | 44.95 |
| Clamping Depth (Decimal Inch) | 1.7700 |
| Overall Length (Decimal Inch) | 7.0000 |
| Overall Length (mm) | 177.80 |
| Balanced to (RPM) | 25000 |
| TIR (Decimal Inch) | 0.0002 |
| Coolant Type | Through-Spindle & DIN Flange |
| Retention Knob Thread Size | 1-8 |
