Seco - WNMG432 FF2 Grade TP1501 Carbide Turning Insert - Al2O3 Finish, 80° Trigon, 1/2" Inscr Circle, 3/16" Thick, 1/32" Corner Radius - Exact Tooling

Seco - WNMG432 FF2 Grade TP1501 Carbide Turning Insert - Al2O3 Finish, 80° Trigon, 1/2" Inscr Circle, 3/16" Thick, 1/32" Corner Radius

Item #: 43018100

Brand: Seco

Model #: 15668

Features and Benefits

Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.

Product Specifications
Insert Style WNMG
Insert Size 432
Material Carbide
Inscribed Circle (Decimal Inch) 0.5000
Inscribed Circle (Inch) 1/2
Thickness (Inch) 3/16
Thickness (Decimal Inch) 0.1875
Corner Radius (Inch) 1/32
Corner Radius (Decimal Inch) 0.0313
Manufacturer's Grade TP1501
Coating Al2O3
Chip Breaker FF2
Hole Diameter (mm) 5.15
Hole Diameter (Decimal Inch) 0.2028
Rake Negative
Relief Angle 0
Coating Process Duratomic
Primary Workpiece Material P
Secondary Workpiece Material K
Included Angle 80
Cutting Direction Neutral
Insert Hand Neutral
Insert Holding Method Pin & Clamp
Cutting Edge Style Honed
FullRadius No
Shape Trigon
