Sandvik Coromant - 4 Inserts, 1-1/2" Cut Diam, 3/4" Arbor Diam, 6.35mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 50mm High, RCKT 13 04 00 Insert Compatibility, Series CoroMill 200
Item #: 43073469
Brand: Sandvik Coromant
Model #: 5739068
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 38.10 |
| Cutting Diameter (Inch) | 1-1/2 |
| Cutting Diameter (Decimal Inch) | 1.5000 |
| Arbor Hole Diameter (mm) | 19.05 |
| Arbor Hole Diameter (Inch) | 3/4 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.00 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | RCKT 13 04 00 |
| Series | CoroMill 200 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 6.35 |
| Maximum Depth of Cut (Decimal Inch) | 0.2500 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | RA200 |
| Number of Flutes | 4 |
| Rake | Negative |
| Hub Diameter (mm) | 19.05 |
| Hub Diameter (Decimal Inch) | 0.7500 |
| Hub Diameter (Inch) | 3/4 |
| Keyway Width (mm) | 8.15 |
| Keyway Width (Decimal Inch) | 0.3209 |
| Maximum Body Diameter (Decimal Inch) | 1.5000 |
| Number of Adjustable Pockets | 0 |
| Maximum RPM | 18800 |
| Pitch | Close |
| Cutting Edge Length (Inch) | 1/4 |
| Cutting Edge Length (Decimal Inch) | 0.2500 |
| ISO Number | RA200-038R19-13M |
| Complete Insert Compatibility | RCKT 13 04 00 |
| Toolholder Material | Steel |
