Kyocera - 6 Inserts, 3" Cut Diam, 0.555" Arbor Diam, 0.618" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 1.969" High, BDMT 1704 Insert Compatibility, Through Coolant
Item #: 43394477
Brand: Kyocera
Model #: 8607053
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 3.0000 |
| Arbor Hole Diameter (Decimal Inch) | 0.5550 |
| Lead Angle | 0 |
| Overall Height (Decimal Inch) | 1.9690 |
| Insert Compatibility | BDMT 1704 |
| Through Coolant | Yes |
| Maximum Depth of Cut (Decimal Inch) | 0.6180 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | MEC |
| Number of Flutes | 6 |
| Cutting Rake Angle | -7 |
| Rake | Negative |
| Keyway Width (Decimal Inch) | 0.3750 |
| Keyway Depth (Decimal Inch) | 0.2230 |
| Maximum RPM | 12250 |
| Counterbore Diameter (Decimal Inch) | 0.8270 |
| Complete Insert Compatibility | BDMT 170402FR; BDMT 170404ER-JS; BDMT 170404ER-JT; BDMT 170404FR; BDMT 170404FR-JA; BDMT 170408ER-JS; BDMT 170408ER-JT; BDMT 170408FR-JA; BDMT 170412ER-JT; BDMT 170416ER-JT; BDMT 170420ER-JT; BDMT 170420FR-JA; BDMT 170424ER-JT; BDMT 170431ER-JT; BDMT 1704 |
