Value Collection - 125 VDC, 250 VAC, 25 Amp, Time Delay General Purpose Fuse - 2" OAL, 200 kA Rating, 9/16" Diam
Item #: 43581818
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
General purpose or class H non-renewable cartridge fuse have a single element and two cylindrical end caps designed for disposable, one-time use
Time delay fuses, also known as duel-element fuses, are designed to allow for a surge in electricity during a short time before overloading or shorting out. They can protect equipment from overload and allow for greater starting amperage.
| Product Specifications | |
|---|---|
| Fuse Type | General Purpose |
| Fuse Class | RK5 |
| Amperage | 25 |
| Voltage | 125 VDC; 250 VAC |
| Fuse Timing | Time Delay |
| Fuse Body Type | Cartridge |
| Overall Length (Decimal Inch) | 2.0000 |
| Overall Diameter (Inch) | 9/16 |
| Number of Elements | 2 |
| Interrupting Rating (A) | 200000.00 |
| Interrupting Rating (kA) | 200 |
| Standards Met | CSA Certified; Federal Specification W-F-1814 QPL; UL 198L; UL Listed |
