Value Collection - 300 VDC, 600 VAC, 2.5 Amp, Time Delay General Purpose Fuse - 1-1/2" OAL, 300 at AC kA Rating, 0.41" Diam
Item #: 43592641
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
General purpose or class H non-renewable cartridge fuse have a single element and two cylindrical end caps designed for disposable, one-time use
Time delay fuses, also known as duel-element fuses, are designed to allow for a surge in electricity during a short time before overloading or shorting out. They can protect equipment from overload and allow for greater starting amperage.
| Product Specifications | |
|---|---|
| Fuse Type | General Purpose |
| Fuse Class | CC |
| Amperage | 2.50 |
| Voltage | 300 VDC; 600 VAC |
| Fuse Timing | Time Delay |
| Fuse Body Type | Cartridge |
| Overall Length (Decimal Inch) | 1.5000 |
| Overall Diameter (Decimal Inch) | 0.4100 |
| Number of Elements | 2 |
| Interrupting Rating (A) | 300000 @ AC |
| Interrupting Rating (kA) | 300 @ AC |
| Standards Met | CSA HRCI-MISC Certified; UL 198c |
