Turning Insert: TCMT21.51PSS T9225, Carbide

Item #: 20855045
Brand: Tungaloy
Model #: 6781119

Product Specifications

ANSI Insert Code TCMT21.51

ISO Insert Code TCMT110204

Relief Angle 7

Insert Style TCMT

Corner Radius (Inch) 1/64

Corner Radius (Decimal Inch) 0.0157

Included Angle 60

Manufacturer Grade T9225

Coating/Finish Titanium; Al2O3

Wiper Edge No

Insert Hand Neutral

Insert Thickness (Inch) 3/32

Insert Thickness (Decimal Inch) 0.0938

Series TCMT-PSS

Inscribed Circle (Decimal Inch) 0.2500

Inscribed Circle (Inch) 1/4

Insert Material Carbide

Insert Shape T - Triangle

Chip Breaker Operation Finishing

Grade Characteristics Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Steel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness

Side Clearance Positive

Number Of Cutting Edges 3

Insert Shape Code T

Hole Diameter (Decimal Inch) 0.1100

Maximum Depth of Cut (Decimal Inch) 0.0787

Insert Holding Method Screw

Clearance Code C

Tolerance Code M

Coating Process CVD

Length Range (Decimal Inch) 0.4000 - 0.5000

Rake Positive

Insert Length (Decimal Inch) 0.4330

Primary Workpiece Material Stainless Steel; Cast Iron; Steel

Primary Workpiece Material Code P; K; M

Iso Code TCMT110204-PSS T9225

Standards ISO; ANSI

Manufacturers Catalog Number 6781119

Material Grade P25; P15

Proprietary Coating Designation Multilayer Coating

Coating Classification CVD

Chip Breaker PSS

Rake Angle 10

Cutting Edge Style Honed; Chamfered

Industry Standard Number TCMT 21.51 PSS

Width (Decimal Inch - 4 Decimals) 0.4330

Multi-Use Tool Yes

Full Radius No

Multi-Use Application Facing; Turning; Boring

ANSI Size Code 21.51

ISO Size Code 110204

UNSPSC Code 23242105

Insert Size Code 21.51
