Allied Machine and Engineering - 127mm Max Drill Depth, 4.1201" Diam, Indexable Insert Drill - 6 Inserts, 50mm Shank Diam, Straight Shank
Item #: 43935634
Brand: Allied Machine and Engineering
Model #: OP4-1S-50M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | OP |
| Drill Diameter (Decimal Inch) | 4.1201 |
| Maximum Drill Depth (mm) | 127.00 |
| Maximum Drill Depth (Decimal Inch) | 5.0000 |
| Shank Type | Straight |
| Shank Diameter (mm) | 50.00 |
| Shank Diameter (Decimal Inch) | 1.9685 |
| Cutting Direction | Right Hand |
| Through Coolant | NonThrough Coolant |
| Number of Drill Inserts | 6 |
| Maximum Drill Diameter (Decimal Inch) | 5.6201 |
| Maximum Drill Diameter (mm) | 142.75 |
| Overall Length/Projection (mm) | 232.40 |
| Overall Length/Projection (Decimal Inch) | 9.1496 |
| Insert Compatibility | OP-05T308-1H; OP-05T308-1P; OP-05T308-1T; OP-05T308-2H; OP-05T308-2P; OP-05T308-A; OP-05T308-H; OP-05T308-HHR; OP-05T308-N; OP-05T308-P; OP-05T308-PHR; OP-05T308-T |
| Body Length (Decimal Inch) | 6.0000 |
| Body Length (mm) | 152.40 |
| Shank Length (mm) | 80.00 |
| Shank Length (Decimal Inch) | 3.1496 |
| Series | Opening Drill |
