Allied Machine and Engineering - 267mm Max Drill Depth, 3.5xD, 2.8" Diam, Indexable Insert Drill - 6 Inserts, 40mm Shank Diam, Straight Shank
Item #: 43935766
Brand: Allied Machine and Engineering
Model #: R46X35-40M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | R |
| Drill Diameter (Decimal Inch) | 2.8000 |
| Maximum Drill Depth (mm) | 267.00 |
| Maximum Drill Depth (Decimal Inch) | 10.5118 |
| Shank Type | Straight |
| Shank Diameter (mm) | 40.00 |
| Shank Diameter (Decimal Inch) | 1.5748 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 3.5xD |
| Number of Drill Inserts | 6 |
| Maximum Drill Diameter (Decimal Inch) | 3.0000 |
| Maximum Drill Diameter (mm) | 76.20 |
| Overall Length/Projection (mm) | 369.90 |
| Overall Length/Projection (Decimal Inch) | 14.5630 |
| Insert Compatibility | OP-05T308-1H; OP-05T308-1P; OP-05T308-1T; OP-05T308-2H; OP-05T308-2P; OP-05T308-A; OP-05T308-H; OP-05T308-HHR; OP-05T308-N; OP-05T308-P; OP-05T308-PHR; OP-05T308-T |
| Body Length (Decimal Inch) | 11.8071 |
| Body Length (mm) | 299.90 |
| Shank Length (mm) | 70.00 |
| Shank Length (Decimal Inch) | 2.7559 |
| Series | Revolution Drill |
| Coolant Hole Thread Type | BSP |
| Shank End Coolant Hole Thread Size (Inch) | 1/4 |
