Allied Machine and Engineering - 11 to 11.99mm Diam, Straight Shank, 15.88mm Body Shank Diam, Combo Chamfer and Countersink Drill - TCMT 110204 Insert, 90.09mm OAL
Item #: 43937010
Brand: Allied Machine and Engineering
Model #: 60111C45-16FM
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Straight Shank |
| Maximum Drill Diameter (mm) | 11.99 |
| Maximum Drill Diameter (Decimal Inch) | 0.4720 |
| Minimum Drill Diameter (mm) | 11.00 |
| Minimum Drill Diameter (Decimal Inch) | 0.4331 |
| Body Shank Diameter (mm) | 15.88 |
| Body Shank Diameter (Decimal Inch) | 0.6250 |
| Number of Drill Inserts | 1 |
| Insert Style | TCMT 110204 |
| Body Diameter (mm) | 24.21 |
| Body Diameter (Decimal Inch) | 0.9531 |
| Overall Length (mm) | 90.09 |
| Overall Length (Decimal Inch) | 3.5469 |
| Insert Holding Method | Screw |
| Shank Length (mm) | 47.63 |
| Shank Length (Decimal Inch) | 1.8750 |
| Through Coolant | Through Coolant |
| Series | 11; GEN3SYS XT |
