Tool-Flo - Internal Thread, Left Hand Cut, 2" Shank Width x 2" Shank Height Indexable Threading Toolholder - 16" OAL, LDS 54 Insert Compatibility, LNFL Toolholder, Series Laydown
Item #: 44198836
Brand: Tool-Flo
Model #: 94308064
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Type | Internal |
| Hand of Holder | Left Hand |
| Shank Width/Diameter (Decimal Inch) | 2.0000 |
| Shank Width/Diameter (Inch) | 2 |
| Shank Height (Inch) | 2 |
| Shank Height (Decimal Inch) | 2.0000 |
| Overall Length (Decimal Inch) | 16.0000 |
| Overall Length (Inch) | 16 |
| Insert Compatibility | LDS 54 |
| Series | Laydown |
| Toolholder Style | LNFL |
| Through Coolant | No |
| Multi-Use Tool | No |
| Insert Holding Method | Pin & Clamp |
| Center to Cutting Edge (Decimal Inch) | 1.0000 |
| Minimum Bore Diameter (Decimal Inch) | 2.0000 |
| Insert Inscribed Circle (Inch) | 5/8 |
| Insert Inscribed Circle (Decimal Inch) | 0.6250 |
