Iscar - SVJC, Right Hand Cut, 93° Lead Angle, 1" Shank Height x 1" Shank Width, Neutral Rake Indexable Turning Toolholder - 6" OAL, VC..33.. Insert Compatibility, Series Isoturn, JetHPLine
Item #: 45379260
Brand: Iscar
Model #: 3603204
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Right Hand |
| Toolholder Style | SVJC |
| Rake | Neutral |
| Rake Angle | 0 |
| Series | Isoturn; JetHPLine |
| Lead Angle | 93 |
| Shank Width (Decimal Inch) | 1.0000 |
| Shank Height (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 6.0000 |
| Insert Compatibility | VC..33.. |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.2500 |
| Head Length (Decimal Inch) | 1.6500 |
