Iscar - Shank Connection, 1/8" Cutting Width, 5/8" Depth of Cut, 2" Cutter Diam, 8 Tooth Indexable Slotting Cutter - 3/4" Shank Diam, ETS-LN08 Toolholder, LNET Insert, Right Hand Cutting Direction
Item #: 45386919
Brand: Iscar
Model #: 3105360
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shank |
| Cutting Width (Decimal Inch) | 0.1250 |
| Maximum Depth of Cut (Decimal Inch) | 0.6250 |
| Cutter Diameter (Decimal Inch) | 2.0000 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Number of Teeth | 8 |
| Toolholder Style | ETS-LN08 |
| Series | Mini-TangSlot(ETS-LN08) |
| Insert Style | LNET |
| Number of Cutter Inserts | 4 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.1250 |
| Maximum Cutting Width (Decimal Inch) | 0.1250 |
| Cutting Radius (Inch) | 1/64 |
| Shank Length (Decimal Inch) | 4.1250 |
| Weldon Flat | Yes |
| Complete Insert Compatibility1 | LNET 081804-TN-N |
