Iscar - Arbor Hole Connection, 0.106" Cutting Width, 59mm Depth of Cut, 200mm Cutter Diam, 40mm Hole Diam, 14 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFN, GSFU Insert, Right Hand Cutting Direction
Item #: 45387545
Brand: Iscar
Model #: 2300697
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.1060 |
| Maximum Depth of Cut (mm) | 59.00 |
| Cutter Diameter (mm) | 200.00 |
| Hole Diameter (mm) | 40.00 |
| Number of Teeth | 14 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFN; GSFU |
| Staggered Tooth | No |
| Number of Cutter Inserts | 14 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Clamp |
| Maximum RPM | 400 |
| Minimum Cutting Width (Decimal Inch) | 0.1060 |
| Maximum Cutting Width (mm) | 3.54 |
| Hub Diameter (mm) | 80.00 |
| Cutting Radius (Inch) | 1/32 |
| Cutter Body Width (mm) | 2.40 |
| Complete Insert Compatibility1 | GSFN 1.6; GSFU 1.6; GSFU 1.7 |
