Panduit - 2 AWG Noninsulated Lug Connection Square Ring Terminal - 1/2" Stud, 5-1/2" OAL x 5.31" Wide, Tin Plated Aluminum Contact
Item #: 46795290
Brand: Panduit
Model #: LAM4LD600-12-1
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Terminal Type | Square |
| Insulation Type | NonInsulated |
| Connection Type | Lug |
| Compatible Wire Size (AWG) | 2 |
| Compatible Wire Size (kcmil) | 600 |
| Stud Size (Inch) | 1/2 |
| Contact Material | Aluminum |
| Thickness (mm) | 9.65 |
| Thickness (Decimal Inch) | 0.3800 |
| Thickness (Inch) | 0.3800 |
| Ring Width (Inch) | 5.3100 |
| Ring Width (Decimal Inch) | 5.3100 |
| Ring Width (mm) | 134.87 |
| Overall Length (mm) | 139.70 |
| Overall Length (Inch) | 5-1/2 |
| Overall Length (Decimal Inch) | 5-1/2 |
| Contact Plating | Tin |
