Kennametal - 200mm Cut Diam, 10mm Max Depth, 60mm Arbor Hole, 9 Inserts, RCGT 2006... Insert Style, Indexable Copy Face Mill - 12,500 Max RPM, 63mm High, Series KSRM
Item #: 46870606
Brand: Kennametal
Model #: 3095653
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 200.00 |
| Cutting Diameter (Decimal Inch) | 7.8740 |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Arbor Hole Diameter (mm) | 60.00 |
| Arbor Hole Diameter (Decimal Inch) | 2.3622 |
| Overall Height (mm) | 63.00 |
| Overall Height (Decimal Inch) | 2.4803 |
| Series | KSRM |
| Number of Cutter Inserts | 9 |
| Insert Compatibility | RCGT 2006... |
| Maximum RPM | 12500 |
| Insert Holding Method | Screw |
| Hub Diameter (Decimal Inch) | 5.1181 |
| Insert Inscribed Circle (mm) | 20.00 |
| Insert Inscribed Circle (Decimal Inch) | 0.7874 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | RCGT 2006MO.. |
