Kennametal - Arbor Hole Connection, 0.2362" Cutting Width, 0.6299" Depth of Cut, 80mm Cutter Diam, 1-1/16" Hole Diam, 4 Tooth Indexable Slotting Cutter - 90° LN Toolholder, LNE 1235... Insert
Item #: 46885950
Brand: Kennametal
Model #: 1131438
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 6.00 |
| Cutting Width (Decimal Inch) | 0.2362 |
| Maximum Depth of Cut (mm) | 16.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.6299 |
| Cutter Diameter (mm) | 80.00 |
| Cutter Diameter (Decimal Inch) | 3.1496 |
| Hole Diameter (mm) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.0630 |
| Number of Teeth | 4 |
| Toolholder Style | 90 LN |
| Series | LN |
| Insert Style | LNE 1235... |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.2362 |
| Maximum Cutting Width (Decimal Inch) | 0.2756 |
| Maximum Cutting Width (mm) | 7.00 |
| Hub Diameter (mm) | 44.00 |
| Hub Diameter (Decimal Inch) | 1.7323 |
| Cutter Body Width (mm) | 12.00 |
| Cutter Body Width (Decimal Inch) | 0.4724 |
