Kennametal - 142.33mm Cut Diam, 40mm Arbor Hole, 8mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 6 Inserts, HNPJ 1307... Insert, Right Hand Cut, 6 Flutes, Through Coolant, Series Dodeka Max
Item #: 46886214
Brand: Kennametal
Model #: 4060936
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 142.33 |
| Cutting Diameter (Decimal Inch) | 5.6036 |
| Arbor Hole Diameter (mm) | 40.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.5748 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | HNPJ 1307... |
| Series | Dodeka Max |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 8.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | KSHR |
| Number of Flutes | 6 |
| Hub Diameter (Decimal Inch) | 3.5433 |
| Hub Diameter (mm) | 90.00 |
| Maximum Body Diameter (Decimal Inch) | 5.3920 |
| Maximum RPM | 5050 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | HNPJ 130720ANSNGD |
