Kennametal - 112.8mm Cut Diam, 32mm Arbor Hole, 6.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 14 Inserts, HNGX 0905... Insert, Right Hand Cut, 14 Flutes, Series HexaCut
Item #: 46886982
Brand: Kennametal
Model #: 2016109
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 112.80 |
| Cutting Diameter (Decimal Inch) | 3.9370 |
| Arbor Hole Diameter (mm) | 32.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.2598 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 1.9685 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | HNGX 0905... |
| Series | HexaCut |
| Maximum Depth of Cut (mm) | 6.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.2560 |
| Number of Cutter Inserts | 14 |
| Cutter Style | M750 |
| Number of Flutes | 14 |
| Hub Diameter (mm) | 100.00 |
| Maximum RPM | 3400 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | HNGX 0905... |
