Harvey Tool - Single Profile Thread Mills; Maximum Pitch (mm): 1.00 ; Minimum Pitch (mm): 1.00 ; Thread Type: Internal/External ; Minimum Nominal Diameter (mm): 6 ; Cutting Diameter (Decimal Inch): 4.8000 ; Shank Diameter (mm): 6.0000
Item #: 46979159
Brand: Harvey Tool
Model #: 882130
Product Specifications
Single Profile Thread Mills; Maximum Pitch (mm): 1.00 ; Minimum Pitch (mm): 1.00 ; Thread Type: Internal/External ; Minimum Nominal Diameter (mm): 6 ; Cutting Diameter (Decimal Inch): 4.8000 ; Shank Diameter (mm): 6.0000
| Maximum Pitch (mm) | 1.00 |
| Minimum Pitch (mm) | 1.00 |
| Thread Type | Internal/External |
| Minimum Nominal Diameter (mm) | 6 |
| Cutting Diameter (Decimal Inch) | 4.8000 |
| Shank Diameter (mm) | 6.0000 |
| Material | Solid Carbide |
| Number of Flutes | 4 |
| Neck Diameter (Decimal Inch) | 2.8800 |
| Neck Length (Decimal Inch) | 0.5512 |
| Thread Size | M6x1.00 |
| Overall Length (Decimal Inch) | 1.96850 |
| Overall Length (mm) | 50.0000 |
| Thread Standard | UN 60 Degrees |
| Finish/Coating | Uncoated |
