Harvey Tool - Single Profile Thread Mills; Maximum Pitch (mm): 1.25 ; Minimum Pitch (mm): 1.00 ; Thread Type: Internal/External ; Minimum Nominal Diameter (mm): 8 ; Cutting Diameter (Decimal Inch): 6.0000 ; Shank Diameter (mm): 6.0000
Item #: 46985032
Brand: Harvey Tool
Model #: 882132
Product Specifications
Single Profile Thread Mills; Maximum Pitch (mm): 1.25 ; Minimum Pitch (mm): 1.00 ; Thread Type: Internal/External ; Minimum Nominal Diameter (mm): 8 ; Cutting Diameter (Decimal Inch): 6.0000 ; Shank Diameter (mm): 6.0000
| Maximum Pitch (mm) | 1.25 |
| Minimum Pitch (mm) | 1.00 |
| Thread Type | Internal/External |
| Minimum Nominal Diameter (mm) | 8 |
| Cutting Diameter (Decimal Inch) | 6.0000 |
| Shank Diameter (mm) | 6.0000 |
| Material | Solid Carbide |
| Number of Flutes | 4 |
| Neck Diameter (Decimal Inch) | 3.6000 |
| Neck Length (Decimal Inch) | 0.7087 |
| Thread Size | M8x1.00 - M8x1.25 |
| Overall Length (Decimal Inch) | 1.96850 |
| Overall Length (mm) | 50.0000 |
| Thread Standard | UN 60 Degrees |
| Finish/Coating | Uncoated |
