Walter - 32mm Cut Diam, 15mm Max Depth of Cut, 20mm Shank Diam, 110mm OAL, Indexable Square Shoulder End Mill - Cylindrical Shank, 0° Lead Angle, Through Coolant, Series M2131-A-L
Item #: 47293071
Brand: Walter
Model #: 6836944
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 32.00 |
| Cutting Diameter (Decimal Inch) | 1.2600 |
| Shank Type | Cylindrical |
| Shank Diameter (mm) | 20.00 |
| Shank Diameter (Decimal Inch) | 0.7870 |
| Overall Length/Projection (mm) | 110.00 |
| Overall Length/Projection (Decimal Inch) | 4.3310 |
| Lead Angle | 0 |
| Series | M2131-A-L |
| Through Coolant | Coolant Through |
| Maximum Depth of Cut (mm) | 15.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.591 |
| Number of Cutter Inserts | 2 |
| Number of Flutes | 2 |
| Maximum RPM | 29300 |
| Toolholder Material | Steel |
