Kennametal - 4 Inserts, 3" Cut Diam, 1" Arbor Diam, 14mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 1-3/4" High, E.. 14.. Insert Compatibility, Through Coolant, Series Mill 1-14
Item #: 47499934
Brand: Kennametal
Model #: 5898597
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 3 |
| Cutting Diameter (Decimal Inch) | 3.0000 |
| Arbor Hole Diameter (Inch) | 1 |
| Lead Angle | 0 |
| Overall Height (Inch) | 1-3/4 |
| Insert Compatibility | E.. 14.. |
| Series | Mill 1-14 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 14.00 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | M1 |
| Number of Flutes | 4 |
| Hub Diameter (mm) | 55.56 |
| Maximum Body Diameter (Decimal Inch) | 2.9280 |
| Maximum RPM | 19600 |
| Coolant Hole Diameter (Decimal Inch) | 0.0940 |
| Toolholder Material | Steel |
