Seco - Shell Mount Connection, 0.787" Cutting Width, 44.31mm Depth of Cut, 160mm Cutter Diam, 40mm Hole Diam, 6 Tooth Indexable Slotting Cutter - R335.25 Toolholder, XNHQ 12 Insert, Right Hand Cutting Direction
Item #: 48095541
Brand: Seco
Model #: 14095
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount |
| Cutting Width (mm) | 20.00 |
| Cutting Width (Decimal Inch) | 0.7870 |
| Maximum Depth of Cut (mm) | 44.31 |
| Cutter Diameter (mm) | 160.00 |
| Hole Diameter (mm) | 40.00 |
| Number of Teeth | 6 |
| Toolholder Style | R335.25 |
| Series | R335.25 |
| Insert Style | XNHQ 12 |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 12 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Insert Holding Method | Screw |
| Maximum RPM | 5700 |
| Number of Flutes | 12 |
| Maximum Cutting Width (mm) | 20.00 |
| Hub Diameter (mm) | 70.00 |
| Keyway Width (mm) | 16.40 |
| Through Coolant | Yes |
