Seco - 40mm Cutting Diam, 32mm Shank Diam, 8mm Max Depth of Cut, Straight Shank Indexable Copy End Mill - 4 Inserts, LOEX Insert, R217.94 Toolholder
Item #: 48329692
Brand: Seco
Model #: 00489
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 40.00 |
| Shank Type | Straight Shank |
| Shank Diameter (mm) | 32.00 |
| Overall Length/Projection (Decimal Inch) | 5.1180 |
| Series | Square T4-08 |
| Maximum Depth of Cut (mm) | 8.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Number of Cutter Inserts | 4 |
| Cutter Style | R217.94 |
| Insert Compatibility | LOEX |
