Mead - 1/4" Stroke x 1/4" Bore Double Acting Air Cylinder - 10-32 Port, 6-32 Rod Thread, 125 Max psi, -40 to 400°F
Item #: 48498760
Brand: Mead
Model #: MA250X0.25DARB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Double Acting |
| Bore Size (Inch) | 1/4 |
| Rod Diameter (Decimal Inch) | 0.140 |
| Stroke Length (Inch) | 1/4 |
| Port Size | 10-32 |
| Port Type | UNF |
| Length (Decimal Inch) | 1.550 |
| Mount Thread | 3/8-32 |
| Maximum Working Pressure (psi) | 125 |
| Rod Thread Size | 6-32 |
| Style | Threaded Body |
