Woodhead Electrical - 2 Operator, Mushroom Head Pendant Control Station - No Legend, No On/Off Switch, NO/NC Contact, NEMA 4X
Item #: 48681191
Brand: Woodhead Electrical
Model #: 5052-1
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Control Station Type | Pendant Control Station |
| Number of Operators | 2 |
| Legend Markings | No Legend |
| Switch Action | No On/Off |
| Contact Configuration | NO/NC |
| Operator Type | Mushroom Head |
| NEMA Rating | 4X |
| Interlock Style | Mechanical Interlock |
| Color | Yellow |
| Amperage | 3 |
| Voltage | 125 VAC; 125/250 V; 250 VAC |
| Overall Height (Decimal Inch) | 7.4000 |
| Overall Width (Decimal Inch) | 3-1/2 |
| Overall Depth (Decimal Inch) | 2.3000 |
| Ingress Protection Rating | IP56 |
| Includes | Strain Relief |
| Standards Met | cULus; UL Listed File E70531 |
